TYT TH-9000D PLUS 65W 200 Channels SINGLE BAND RADIO 136-174Mhz or 220-260Mhz or 400-490 MHz
Main Features:
Functions:
Frequency Range: 136-174MHz or 220-260MHz or 400-490MHz
– Output Power: VHF: 10W/25W/65W UHF: 45W/25W/10W
– 8 Group’s of Scrambler
– 1750Hz Tone CTCSS/DCS setting & scanning
– 0-9 SQL grade setting
– Frequency/Channel scanning
– High/Mid/Low power selectable
– Voice commander
– Repeater offset shift
– Keypad lock function
– Contact book
– Battery voltage display
– DTMF/2 tone/5 tone
– ANI ID
– Remote kill/ stun/ activate/ revive
– Emergency alarm
– Wide/Narrow band setting
– TX inhibit
– Busy Channel Lock-Out
– Channel name editing
– Reverse frequency
– Talk around
– Scrambler(Optional)
– Voice prompt
– Time-out Timer
– Auto Power off
– VFO step setting:5/6.25/10/12.5/20/25/50kHz
Specification:
General:
Frequenvy Range: 136-174/245-246/400-490MHz
Channel Capacity: 200
Channel Spacing: 5/6.25/8.33/10/12.5/15/20/25/30/50KHz
Freruency Stability: 2.5ppm
Operating Temperature: -20℃ ~ + 60℃
Operating Voltage: 13.8V DC ± 15%
Dimension(HxWxD): 145mm x190mm x47mm
Weight(with bracket): 1200g
Receiver:
Reference Sensitivity: 0.2μV @ 12dB SINAD
Operating Bandwidth: 60dB@12.5KHz /70dB@25KHz
Adjacent Channel Selectivity: 60dB@12.5KHz 70dB@25KHz
Inter-modulation Rejection: ≥60dB/ ≥65dB
Spurious Response Rejection: ≥70dB
Rated Audio Response: +1-+3dB
Rated Audio Distortion: <5%
FM Hum&Noise: ≥40dB@25KHz /≥45KHz @12.5KHz
Transmitter:
RF Power: 45W/25W/10W (UHF)/60W/25W/10W (VHF)
Frequency Modulation: 11kΦF3E / 16kΦF3E
Modulation Distortion :< 5% FM Noise: ≥36dB@25KHz /≥40KHz @12.5KHz
Adjacent Channel Power: ≥60dB@12.5KHz /≥70KHz @25KHz
Audio Response: +1-+3dB
Audio Distortion: <5%
