WLN KD-C1 Plus Mini Walkie Talkie UHF 16 Channels Two Way Radio FM Transceiver
NOTE :
KD-C1 Plus is quite different from KD-C1.
If you need the software or you have any technical problem , please contact us freely.
Main feaures:
- Channel Display
- Remote Alarm
- Scanning
- Monitoring
- VOX
- TOT
- Keyboard Lockout
- Busy Channel Lockout
- High Low Power Selection
- Cycle indicator Fashion Design
- Chinese/English Voice Prompt
- Power Saving Mode
- Low Battery Warning
- Voice Companding
- Scrambling Function
- Programming Encryption Function
- Special Signaling
- 50 CTCSS / 208DCS
|
General Specifications |
|
|
Frequency Range |
UHF 400-470MHz |
|
Channel Capacity |
16 |
|
Channel Spacing |
25KHz |
|
Operated Voltage |
3.7 V |
|
Battery |
1500MAh Li-ion |
|
Battery Life(5-5-90 duty cycle) |
About 8 hours |
|
Frequency Stability |
±2.5ppm |
|
Operated Temperature |
-30°c-+60°c |
|
Dimensions (L×W×H) |
136*56*21mm |
|
Weight (with battery/antenna) |
116g |
|
Communication Range |
about 2km |
|
Transmitter |
|
|
RF Power Output |
2W |
|
Modulation |
F3E |
|
Spurious Emission |
≤65dB |
|
FM Noise |
≤-45dB(W) ≤-40dB (N) |
|
Audio Distortion |
≤5% |
|
Transmitting Current |
≤1.A |
|
Receiver |
|
|
Sensitivity |
≤0.16 uV (12dB SINAD) |
|
Selectivity |
55dB/50dB |
|
Intermodulation |
≥60dB |
|
Adjacent Channel Selectivity |
≥60dB |
|
FM Noise |
45dB/40dB |
|
Audio Power Output |
>300mW |
|
Audio Distortion |
≤5% |
|
Standby Current |
≈20mA (with battery save on) |
