NEW KVE520A Vector Color Graphic Impedance Antenna Analyzer Meter for VHF/UHF Amateur HAM Two Way Radio
Introductions:
KVE520A Vector Impedance Antenna Analyzer is based on the KVE520 platform development with the KVE520 operation is basically is the same, Most of the instructions is from KVE520 opearatinq system.
KVE520A Vector Impedance Antenna Analyzer is based on a 50-ohm measuring shortwave antenna system experimental apparatus. Can accurately measure the reactance X, standing wave SWR, resistance R, and the complex impedance Z parameters. To check and adjust the antenna resonance short, bandwidth matching.
KVE520A Vector Impedance Antenna Analyzer requires users to have a certain radio basic theoretical knowledge and an understanding of the performance of the device; proper operation and in order to better use it.
Second, the developer of the device is a radio amateur, commercial design and try to work with different pursuit:Accuracy! Accuracy! Reliable! Fast! Simple! Easy to use!
KVE520A Vector Impedance Antenna Analyzer has a higher resolution than the commodity machines and precision, test speed, a more friendly user interface, more focus on user experience, portable small size, high quality power management to get more use of time and so on.
Description:
- Lightweight and high precision antenna analyzer, testing and improve your device’s performance.
- Antenna analyzer is widely used in antenna DIY production, installation, debugging, testing maintenance, etc.
- Is usually used to amateur check and adjust the antenna under the condition of resonance, bandwidth, matching.
- KVE520A Vector Impedance Antenna analyzer is based on a 50-ohm measuring shortwave antenna system experimental apparatus.
- Can accurately measure the reactance (X), standing wave SWR, resistance (R), and impedance (Z) parameters.
- KVE520 Vector Impedance Antenna analyzer requires users to have a certain radio basic theoretical knowledge and an understanding of the performance of the device; proper operation and in order to better use it.
- Accuracy! Reliable! Fast! Simple! Easy to use!
Specification:
| Screen | Sharp transflective TFT, 1600 million colors, QVGA resolution. External Hard Mitsubishi scratch-resistant acrylic screen protecter |
| Measuring range | VSWR: 1: 1.00 – 1: 99.99 |
| Impedance: 0.1 – 999.9 Ohm | |
| Resistance: 0.1 – 999.9 Ohm | |
| Reactance: 0.1 – 999.9 Ohm | |
| Frequency range | 133-177/195-280/395-520MHz |
| Frequency Stability | <0.5PPM |
| Frequency step | 1000Hz |
| Output Power | 3dbm (at 438.500MHz) |
| Scan width | 300KHz/1.5MHz/3MHz/6MHz/12MHz/24MHz/42MHz/75MHz (75MHz only in 395-520MHz effective) |
| Scanning step | 1KHz/5KHz/10KHz/20KHz/40KHz/80KHz/140KHz/250KHz (250KHz only in 395-520MHz effective) |
| Power Management | 3.7-V, 1800-mAh Lithium Polymer battery,Removable |
| Charger Source | Any USB port, analyzer accepts Micro-USB port(DC output voltage is 5.0-5.5V, and the current output capacity> 500mA) |
| Charging indicator | LED charging-status indicator |
| Connector | BNC |
Package Includes:
- 1 x Antenna Analyzer KVE520A
- 5 x Connector
If any questions Or bulk order, please contact Ms. Amy Huang:
Email: sales@twowayradio.us
WhatsApp / Skype: +8613860123881
Tel: 86(592)5995025
Fax: 86(592)3720556
