Ailunce AY01 Walkie Talkie Antenna Aluminum Alloy Yagi Antenna High Gain UHF Female Connector
Technical specifications:
Model: AY01
Frequency: UHF
Gain: 7 dBi
Maximum power: 50 W
VSWR: Less than 1.2
Impedance: 50 ohm
Connector: UHF Female
Length: 46 cm
Note: Best communication in the 430-450 MHz band.
Features:
-High gain.
– Strong directionality.
-Strong anti-jamming capability.
-High cost performance.
-Light and robust, easy to install.
– Realize long distance communication.
-Simple construction and easy assembly and disassembly.
| Brand | Ailunce | Ailunce | Ailunce | Ailunce |
| Model | AY01 | AY02 | AY03 | AY04 |
| Picture |  |
 |
 |
 |
| Frequency | UHF 400-470MHz |
UHF 400~470 MHz |
UHF 400~470 MHz |
UHF&VHF 136~174 &400~470 MHz |
|
Connector |
SL16-K | SL16-K | SL16-K | SL16-K |
| Length | 46cm/18.11inch | 45.2cm/17.8inch | 72.5cm/28.5inch | 92.5cm/36.4inch |
| Foldable | NO | YES | NO | NO |
| Product Size | 460x360x60mm | 452x351x47mm | 725x380x48mm | 925×1045×60 mm |
| Package Size | 470*85*85mm | 455*85*50mm | 445*60*60mm | 445*100*100mm |
| Weight | 0.4Kg | 0.4Kg | 0.4Kg | 0.85Kg |
| Gain | 7 dBi | 7 dBi | 9 dBi | UHF9.5 dBi VHF11.5 dBi |
| Element | 3 Elements | 3 Elements | 5 Elements | VHF(3Elements)
UHF(5 Elements) |
|
1.AY01 Description: It can greatly increase communication distance, improve communication quality. Suitable for radio enthusiasts, people with high requirements for wireless communication quality and distance.
Features:
Specifications:
Note: Best communication in the 430-440MHz band.
2.AY02 Brand: Ailunce Model: AY02 Frequency: UHF Length: 45.2cm/17.8inch
Feature •3 Elements •Foldable •High Gain •Strong directionality •Strong anti-jamming •Realize long distance communication •Simple construction and easy assembly and disassembly •Lightweight and sturdy, easy to set up •High-cost performance
3.AY03 Brand: Ailunce Model: AY03 Frequency: UHF Length: 72.5cm/28.5inch
Feature •5 Elements •High Gain •Strong directionality •Strong anti-jamming •Realize long distance communication •Simple construction and easy assembly and disassembly •Lightweight and sturdy, easy to set up •High-cost performance
4.AY04 Brand: Ailunce Model: AY04 Frequency: UHF&VHF Length: 92.5cm/36.4inch
Feature •VHF(3 Elements), UHF(5 Elements) •High Gain •Strong directionality •Strong anti-jamming •Realize long distance communication •Simple construction and easy assembly and disassembly •Lightweight and sturdy, easy to set up •High-cost performance
Package Include(AY01):
Package Includes(AY02) Ailunce AY02 Foldable Yagi Antenna
Package Includes(AY03) Ailunce AY03 High Gain Antenna
Package Includes(AY04) Ailunce AY04 High Gain Antenna |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
